NX SKETCH
User Level: Beginner
Duration: Two 4-Hour Online Sessions
Price Including Materials: Note that all classes have a charge for access to online training materials, inquire for details.
Registration Deadline: Two weeks before start date
INQUIRE ABOUT THIS COURSE
Please complete the form below and one of our training representatives will contact you to discuss scheduling and course details.
Course Overview
During the NX Sketch course you will learn the typical workflow for using NX Sketch to design parts.
Course Objectives
- Basic workflow for creating a sketch
- Starting a sketch
- Create curves
- Reposition Curves
- Dimensions and Relations
- Correct Curves
- External Geometry
- Fully defined sketches
Who Should Attend
- Designers and engineers who are interested in learning about NX Sketch.
Course Materials
- Course Notes
- Course Exercises (including all required related files)
